TC-H334S Spec: I5W/C/WIFI/4mm/V4.1
Mã sản phẩm: TC-H334S Spec: I5W/C/WIFI/4mm/V4.1
3MP Dual Light
EW PT Camera
KEY FEATURES
·Metal+Plastic Housing
·Up to 2304x1296@25fps
·S+265/H.265/H.264
·Min. illumination Color: 0.02Lux@F1.6
·Smart IR, IR Range: 50m
·White Light：20-30m
·Operating Conditions -30℃~60°C, 0~95% RH
·Built-in Mic, SD Card Slot, Reset Button
·Support Wi-Fi
·IP67
Giá: Liên hệ
 |
Chi tiết sản phẩm
SPECIFICATIONS
| Camera | |
| Image Sensor | 1/2.8" CMOS |
| Signal System | PAL/NTSC |
| Min. Illumination | Color: 0.02Lux@ (F1.6, AGC ON), B/W: 0Lux with IR |
| Shutter Time | 1s to 1/100,000s |
| Day & Night | Dual IR Cut Filter with Auto Switch |
| Wide Dynamic Range Lens |
Digital WDR |
| Lens Type | Fixed |
| Focus | 4mm |
| Lens Mount | M12 |
| Aperture | F1.6, Fixed |
| FOV | Horizontal field of view: 90.4° Vertical field of view: 46.8° |
| Illuminator | |
| IR LEDs | 2 |
| IR Range | Up to 50m |
| Wavelength | 850nm |
| White LEDs | 2 |
| Compression Standard | |
| Video Compression | S+265/H.265/H.264 |
| Video Bit Rate | 32Kbps~6Mbps |
| Audio Compression | G.711/G.711U |
| Audio Bit Rate | 8K/16K |
| Image | |
| Max. Resolution | 1920x1080 |
| Main Stream | PAL: 25fps (2304×1906, 1920×1080, 1280×720, 704×576, 640×480) |
| NTSC: 24fps (2304×1906, 1920×1080, 1280×720, 704×480, 640×480) | |
| Sub Stream | PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
| NTSC: 30fps (704×480, 704×240, 640×360, 352×240) | |
| Third Stream | N/A |
| Image Setting | Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
| Image Enhancement | 3D DNR/HLC |
| ROI | N/A |
| OSD | 16×16, 32×32, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions |
| Picture Overlay | N/A |
| Privacy Mask | Yes, 4 regions |
| Smart Defog | Yes |
| Feature | |
| Alarm Trigger | IP Address Conflict |
| Video Analytics | N/A |
| Early Warning(EW) | Yes |
| Network Network Storage |
N/A |
| Protocols | HTTP,TCP/IP,UDP,ICMP,DHCP,DNS,NTP,Telnet,RTSP,CGI |
| System Compatibility | ONVIF (PROFILE S/T), SDK, P2P(Mutually exclusive with Profile G) |
| Remote Connection | 2 |
| Client | Easy7, EasyLive Plus |
| Web Version | Web6 |
| Wi-Fi | |
| Wireless Standards | IEEE802.11b/g/n |
| Frequency Range | 2.4GHz ~ 2.4835 GHz |
| Channel Bandwidth | 20/40MHz |
| Protocols | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM/HT |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transfer Rates | 802.11b: 11Mbps 802.11g: 54Mbps 802.11n: up to 150Mbps |
| Wireless Range | Up to 30m (The performance varies based on actual environment) |
| Power Consumption | 802.11b: 17±1.5dBm@11Mbps 802.11g: 14±1.5dBm@54Mbps 802.11n: 12.5±1.5dBm@150Mbps |
| Interface |
| Communication Interface 1 RJ45 10M/ 100M self adaptive Ethernet port |
| Audio I/O Mic in |
| Alarm I/O N/A |
| Reset Button Yes |
| On-board storage Built-in MicroSD card slot, up to 512 GB |
| General Web Client Language 2 languages English, Turkish |
| Operating Conditions -30℃～60℃, 0～95% RH |
| Power Supply DC 12V±25% |
| Power Consumption MAX: 12W(12V) |
| Protection IP67, Lightning protection, surge protection and voltage transient protection meets EN 55035:2017 |
| Heater N/A |
| Dimensions 139mm(D)x246mm(H) |
| Weight 1Kg |
