TC-C33XN Spec:I3/E/Y/2.8mm
TC-C33XN Spec:I3/E/Y/2.8mm
Mã sản phẩm: TC-C33XN Spec:I3/E/Y/2.8mm

· Metal+Plastic Housing

· Up to 2304X1296@20fps

· S+265/H.265/H.264

· Min. illumination Color: 0.02Lux@F2.0

· Smart IR, IR Range: 30m

· Support tripwire and perimeter

· Built-in Mic, SD Card Slot, Reset Button

· Operating Conditions -35℃~65℃, 0~95% RH

· POE, IP67

Giá: Liên hệ

Chi tiết sản phẩm

Camera
Image Sensor 1/2.7" CMOS
Signal System PAL/NTSC
Min. Illumination Color: 0.02Lux@ (F2.0, AGC ON), B/W: 0Lux with IR
Shutter Time 1s to 1/100,000s
Day & Night Dual IR Cut Filter with Auto Switch
Wide Dynamic Range Digital WDR
Angle Adjustment pan 0~340°, tilt 0~75°, roate 0~360°
Lens
Lens Type Fixed
Focus 2.8mm
Lens Mount M12
Aperture F2.0, Fixed
FOV Horizontal field of view: 100.1
Illuminator
IR LEDs 2
IR Range Up to 30m
Wavelength 850nm
White LEDs/Warmlights N/A
Compression Standard
Video Compression S+265/H.265/H.264
Video Bit Rate 32Kbps~6Mbps
Audio Compression G.711/G.711U/ADPCM
Audio Bit Rate 8K~48Kbps
Max. Resolution 2304X1296
Main Stream PAL: 20fps (2304x1296), 25fps (1920×1080, 1280×720, 704×576, 640×480)
NTSC: 20fps (2304x1296), 30fps (1920×1080,1280×720, 704×480, 640×480)
Sub Stream PAL: 25fps (704×576, 704×288, 640×360, 352×288)
NTSC: 30fps (704×480, 704×240, 640×360, 352×240)
Third Stream N/A
Image Setting Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
Image Enhancement BLC/3D DNR/HLC
ROI N/A
OSD 16×16, 32×32, 48×48, adaptable size, Letters Such as Week, Date, Time, Total 3 Regions
Picture Overlay N/A
Privacy Mask Yes, 4 regions
Smart Defog Yes
Feature
Alarm Trigger Motion Detection, Mask Alarm, IP Address Conflict
Video Analytics Tripwire, Perimeter
Early Warning(EW) N/A
Network
ANR Yes(Only Support Tiandy ANR NVR)
Protocols TCP/IP, HTTP, FTP, DHCP, DNS, DDNS, IPV4, NTP, UDP, Telnet, ICMP, RTP, RTSP, UPnP
System Compatibility ONVIF (PROFILE S/T/G), SDK, P2P(Mutually exclusive with Profile G)
Remote Connection ≤7
Client Easy7, EasyLive
Web Version Web5
Interface
Communication Interface 1 RJ45 10M/ 100M self adaptive Ethernet port
Audio I/O Mic in
Alarm I/O N/A
Reset Button Yes
On-board storage  Built-in MicroSD card slot, up to 512 GB
General
Firmware Version -
Web Client Language 15 languages
English, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai, French, Polish, Dutch, Hebraism, Arabic, Vietnamese
Operating Conditions -35℃~65℃, 0~95% RH
Power Supply DC 12V±25%, PoE (802.3af)
Power Consumption MAX: 6W (12V) MAX: 7W (PoE)
Protection IP67, Lightning protection, surge protection and voltage transient protection meets EN 55035:2017
Heater N/A
Dimensions  Φ116.6×83.7mm (Φ4.59×3.30inch)
Weight 0.3Kg (0.66lb)
