· Cảm biến CMOS 1 / 2,8 inch
· Up to 1920X1080 @ 30 khung hình / giây
· Độ nhạy sáng: 0,01Lux@F2.0
· Chuẩn nén S+ 265 / H.265 / H.264 / M-JPEG
· Nhận dạng khuôn mặt / chụp khuôn mặt / chế độ giám sát thông minh
· Khoảng cách ánh sáng trắng 5m ~ 8m
· IP67, PoE
Camera |
|
Image Sensor |
1/2.8" CMOS |
Signal System |
PAL/NTSC |
Min. Illumination |
Color: 0.01Lux@ (F2.0, ACG ON), B/W: 0Lux with IR |
Shutter Time |
1s to 1/100,000s |
Day & Night |
Dual IR Cut Filter with Auto Switch |
Wide Dynamic Range |
120dB |
Lens |
|
Lens Type |
Fixed |
Focus |
12mm |
Lens Mount |
M12 |
Aperture |
F2.0, Fixed |
FOV |
Horizontal field of view: 26° |
Illuminator |
|
IR LEDs |
2 |
IR Range |
Up to 30m |
Wavelength |
850nm |
White LEDs |
2 |
Compression Standard |
|
Video Compression |
S+265/H.265/H.264/M-JPEG |
Video Bit Rate |
32 Kbps to 16 Mbps |
Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
Audio Bit Rate |
8K~48Kbps |
Image |
|
Max. Resolution |
1920×1080 |
Main Stream |
PAL: 25fps (1920×1080, 1280×960, 1280×720, 704×576, 640×480) |
NTSC: 30fps (1920×1080, 1280×960, 1280×720, 704×480, 640×480) |
|
Sub Stream |
PAL: 25fps (704×576, 704×288, 640×360, 352×288) |
NTSC: 30fps (704×480, 704×240, 640×360, 352×240) |
|
Third Stream |
4CIF |
Image Setting |
Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
Image Enhancement |
BLC/3D DNR/HLC/Corridor Format |
ROI |
Support 7 fixed region of coding |
OSD |
16×16, 24×24,32×32, 48×48, 64x64, adaptable size, Letters Such as Week, Date, Time, Total 5 Regions |
Picture Overlay |
Yes |
Privace Mask |
Yes |
Smart Defog |
Yes |
Feature |
|
Alarm Trigger |
Event Input, Event Output, Motion Detection, Mask Alarm, Disk Full, Disk R/W Error, IP Address Conflict, MAC Address Conflict, FTP Server Exception |
Video Analytics |
Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Parking, On Duty Detection, Video Abnormal, Audio Abnormal |
Early Warning(EW) |
N/A |
Intelligent Coding |
N/A |
Intelligent Image |
N/A |
Intelligent Alarm |
N/A |
Face Detection and Analytics |
|
Operating Mode |
Face recognition, face capture, intelligent monitoring optional, default face recognition |
Face Detection Performance |
Detects up to 32 faces at the same scene |
Face Exposure Brightness |
Default 35, 1-100 brightness optional |
Min. Face Pixel |
Default 80, 19-1920 optional |
Face Recognition |
Yes |
Face Library |
32 |
Face Pictures |
5000 |
Face Library Management |
Retrieve, import, export |
Face Recognition Alert |
Comparision Alarm, stranger alarm |
Precautionary Alert |
N/A |
Network |
|
ANR |
N/A |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, MULTICAST, UPnP, FTP, IPV4, NTP, RTSP, SMTP, IGMP, QoS, PPPoE |
System Compatibility |
ONVIF (PROFILE S), SDK, CGI, P2P |
Remote Connection |
≤7 |
Client |
Easy7, EasyLive |
Web Version |
Web6 |
Interface |
|
Communication Interface |
1 RJ45 10M/100M self adaptive Ethernet port |
Audio |
1/1 |
Alarm |
2/1 |
Reset Button |
N/A |
On-board storage |
N/A |
General |
|
Firmware Version |
NVSS_V20.0.1.20190313_SP1 |
Web Client Language |
English, Simple Chinese |
Operating Conditions |
-35℃~65℃, 0~95% RH |
Power Supply |
DC12V±20%/PoE |
Power Consumption |
MAX: 6W(12V) MAX: 7W(POE) |
Protection |
IP67 |
Heater |
N/A |
Dimensions |
180x94x95 mm (7.09*3.7*3.74 inch) |
Weight |
0.65kg (1.43lb) |
